Description

The TILT MEASURE 24/40 manufactured by Edulabs is a volumetric liquid transfer apparatus engineered for rapid, semi-automatic dispensing of constant reagent volumes. In analytical and industrial chemistry laboratories, performing repetitive liquid dosing with manual pipettes or cylinders can be time-consuming and prone to human error. The tilt measure simplifies this process by combining a reservoir flask and an internal volumetric cup inside a specialized tilting head assembly.

The operating principle of the Edulabs Tilt Measure relies on gravity and geometry. When the entire assembly is tilted backward, liquid from the main reservoir flows into the internal volumetric cup until it overflows, leaving behind an exact, pre-calibrated volume. When the assembly is tilted forward, the measured liquid trapped inside the internal cup drains through the delivery spout into a receiving vessel, while excess liquid in the main chamber flows back into the reservoir base. This simple tilting cycle enables fast, highly repeatable dispensing without needing manual volume setting.

Fabricated from high-purity BORO 3.3 Borosilicate Glass, the apparatus offers high chemical durability and thermal resistance. It remains unaffected by aggressive acids, organic solvents, halogenated compounds, and neutral solutions, ensuring zero contamination of stored reagents. The standardized 24/40 ground glass joint provides a secure, tight seal with the lower reservoir flask, preventing vapor escape and solvent evaporation during repetitive use.

Available in reservoir capacities of 250 ml and 1000 ml with calibrated dosing cups ranging from 10 ml up to 100 ml, the Edulabs Tilt Measure 24/40 is an ideal dispensing tool for quality control routines, agricultural soil testing, water analysis, and pharmaceutical laboratories. Edulabs provides dependable glassware engineered for efficiency, accuracy, and operator safety.

Key Features

• Made from BORO 3.3 Borosilicate Glass for superior chemical and thermal resistance.

• Standardized 24/40 ground glass joint provides a vapor-tight seal with reservoir flasks.

• Tilting mechanism allows rapid, reproducible dispensing of fixed reagent volumes.

• Eliminates the need for manual pipetting or separate measuring cylinders during repetitive tasks.

• Chemically inert glass surface prevents contamination of sensitive reagents.

• Available in dosing chamber volumes of 10 ml, 20 ml, 25 ml, 50 ml, and 100 ml.

• Smooth delivery spout ensures clean liquid transfer with minimal droplet retention.

• High resistance to thermal shock and aggressive acid/solvent exposure.

• Ideal for high-throughput testing environments and routine laboratory workflows.

• Durable glass wall construction ensures long service life in industrial settings.

Technical Specifications

Available Models

Applications

• Repetitive fixed-volume dispensing of acid reagents in environmental testing.

• Fast addition of solvents during high-throughput sample preparation.

• Dosing chemical indicators and buffer solutions in quality control labs.

• Agricultural soil and fertilizer testing procedures.

• Water and wastewater testing laboratories requiring rapid reagent additions.

• Pharmaceutical liquid reagent dispensing in quality assurance workflows.

• Petrochemical sample preparation and reagent addition.

• Food and beverage quality analysis routines.

• Academic laboratory demonstrations of semi-automated volumetric dosing.

• General wet chemistry workflows requiring repeated fixed liquid volumes.
